Package Contains Coilovers Struts and 2 Shocks
You'll be getting two front coilovers and two rear shocks.🚚 Free Worldwide Shipping on All Orders!Shop Now
HomeStore
Fox 3.0 Factory Race Series Adjustable Coilover w/ Reservoir + Rear Shocks Set for 2019-2024 GMC Sierra 1500 4WD RWD w/3" lift w/ UCA
Fox 3.0 Factory Race Series Adjustable Coilover w/ Reservoir + Rear Shocks Set for 2019-2024 GMC Sierra 1500 4WD RWD w/3" lift w/ UCA
Part Numbers & Details
Fox One Year Warranty
Fox's limited one year warranty protects against defects and premature failure.Lifts your vehicle 3.0" in the front
Springs will lift the vehicle 3.0" in the front and 2-3" in the rearImportant Fitment Note
AT4 Model Fits 0-1" Lift ONLY.Fits 4WD & RWD vehicles
This product works for 4WD and RWD vehicles.Important Fitment Note
Non-AT4 requires a minimum of 2” bump stop spacer and a 1” lift blockHardware & Reservoir Clamp Included
All necessary washers, bushings, and nuts included.For Heavy Off Road Use
2.5" diameter one-piece aluminum bodies with external reservoir can take the heat.Adjustable
External compression adjusters allow you to quickly adapt the shocks to a wide variety of terrain and vehicle loadsFully Rebuildable
Maintain and tweak the performance of your shock over a longer lifetime.Specifications
| Part Number | Lift/Lowered | Position | Item | Quantity |
|---|---|---|---|---|
| 883-26-105 | 2-3" Lift | Rear | Shock Absorber | 1 |
| 883-06-175 | 3.0" Lift | Front | Strut & Spring | 1 |
Product Details
FOX Factory Race Series 3.0 Internal Bypass shocks for your truck delivesr position-sensitive damping technology, Dual Speed Compression (DSC) adjustment, and high-speed ready performance in a bolt-on kit.Patented Internal Bypass technology allows for multiple zones of damping control. The result is a comfortable, confident ride with increased damping force through rough terrain. Internal bypass shocks produce more force progressively to control hard bottom-outs, prevent harsh top-outs, and provide an initial catch for landing. Shock fluid bypasses the main piston through a series of bleed holes in the ride zone. As the shock extends past the ride zone in rebound or compression, the bleed holes terminate, forcing fluid through the main piston.A Recirculating Reservoir Bridge enables continuous exchange of shock fluid between the finned external reservoir and body using checked ports, keeping shock temperatures cool for better performance. Type III anodization prevents corrosion and wear of the 3-inch diameter aluminum bodies. The DSC adjuster allows you to dial in your 1500 for load, environment, and driving style.FOX Internal Bypass shocks deliver the support and confidence you need while driving Mach-3 through rugged terrain. Experience race-bred performance next time you leave the pavement.
$2,614.46
Original: $7,469.90
-65%Fox 3.0 Factory Race Series Adjustable Coilover w/ Reservoir + Rear Shocks Set for 2019-2024 GMC Sierra 1500 4WD RWD w/3" lift w/ UCA—
$7,469.90
$2,614.46More Images
Fox 3.0 Factory Race Series Adjustable Coilover w/ Reservoir + Rear Shocks Set for 2019-2024 GMC Sierra 1500 4WD RWD w/3" lift w/ UCA
Part Numbers & Details
Package Contains Coilovers Struts and 2 Shocks
You'll be getting two front coilovers and two rear shocks.Fox One Year Warranty
Fox's limited one year warranty protects against defects and premature failure.Lifts your vehicle 3.0" in the front
Springs will lift the vehicle 3.0" in the front and 2-3" in the rearImportant Fitment Note
AT4 Model Fits 0-1" Lift ONLY.Fits 4WD & RWD vehicles
This product works for 4WD and RWD vehicles.Important Fitment Note
Non-AT4 requires a minimum of 2” bump stop spacer and a 1” lift blockHardware & Reservoir Clamp Included
All necessary washers, bushings, and nuts included.For Heavy Off Road Use
2.5" diameter one-piece aluminum bodies with external reservoir can take the heat.Adjustable
External compression adjusters allow you to quickly adapt the shocks to a wide variety of terrain and vehicle loadsFully Rebuildable
Maintain and tweak the performance of your shock over a longer lifetime.Specifications
| Part Number | Lift/Lowered | Position | Item | Quantity |
|---|---|---|---|---|
| 883-26-105 | 2-3" Lift | Rear | Shock Absorber | 1 |
| 883-06-175 | 3.0" Lift | Front | Strut & Spring | 1 |
Product Details
FOX Factory Race Series 3.0 Internal Bypass shocks for your truck delivesr position-sensitive damping technology, Dual Speed Compression (DSC) adjustment, and high-speed ready performance in a bolt-on kit.Patented Internal Bypass technology allows for multiple zones of damping control. The result is a comfortable, confident ride with increased damping force through rough terrain. Internal bypass shocks produce more force progressively to control hard bottom-outs, prevent harsh top-outs, and provide an initial catch for landing. Shock fluid bypasses the main piston through a series of bleed holes in the ride zone. As the shock extends past the ride zone in rebound or compression, the bleed holes terminate, forcing fluid through the main piston.A Recirculating Reservoir Bridge enables continuous exchange of shock fluid between the finned external reservoir and body using checked ports, keeping shock temperatures cool for better performance. Type III anodization prevents corrosion and wear of the 3-inch diameter aluminum bodies. The DSC adjuster allows you to dial in your 1500 for load, environment, and driving style.FOX Internal Bypass shocks deliver the support and confidence you need while driving Mach-3 through rugged terrain. Experience race-bred performance next time you leave the pavement.
